Griffin Gear Offers A Complete Range of Gear Manufacturing Services
Griffin Gear specializes in the manufacturing of high quality replacement gears. Their manufacturing services cover nearly any industrial application possible. Griffin Gear was founded in 1967. The company has since grown into a full-service gear manufacturing firm. They have the capacity to create complete in-house customized gearing applications, and often under extreme emergency conditions when getting the part to the customer is of utmost importance.
Worm and Worm Gears
Double Helical Gears
Rack and Pinion Gears
6-80mm Bores Metric Gears
And many more Gears are Available
MAAG SH100/140 Shaper
MAAG SH180/300 Shaper
MAAG SH600/735 Shaper
MAAG SH450/5000 Shaper
MAAG 350/500 Shaper
Scheiss 20’ VBM
Hofler Klingelnberg Rapid 2000k
Click the picture below to enlargen the image.
Griffin Gear specializes in the manufacture of high quality replacement gearing, and gearbox rebuilds for any conceivable industrial application. Griffin Gear is your source for extremely large scale projects. The Griffin Gear manufacturing plant is stocked with readymade components, custom gearing, and gearbox building, rebuilding, and gearbox upgrades are also available upon request.
Contact RCS & Associates >>, and for more information, take a moment to view Griffin Gear's website >> for further details on Griffin Gear manufacturing capabilities.
From simple bearing change outs to complete rebuilds, Griffin Gear's gearbox engineers and technicians are ready to assist you with a complete rebuild and repair analysis proposal prior to the rebuild. Our state-of-the-art 15,000 sq. ft. reducer repair facility meets OEM clean room requirements for both disassembly and assembly requirements. For maximum control and flexibility, we manufacture our own quality replacement gearing and components in house.
For over four decades, Griffin Gear has perfected their methods of gear box repair. They are experts in OEM gear box repair. This includes but not limited to the OEM gear box manufacturers listed below:
OEM GEAR BOX MANUFACTURERS:
- Babcock & Wilcox
- Boston gear boxes
- Danieli gear boxes
- Dodge gear boxes
- Ecodyne gear boxes
- Elliott gear boxes
- Falk gear boxes
- Farrel gear boxes
- Flender gear boxes
- Foote Jones
- General Electric
- Hansen gear boxes
- Horsburgh & Scott
- D.O. James
- Link Belt gear boxes
- Lufkin gear boxes
- Marley gear boxes
- Philadelphia gear boxes
- Pomini gear boxes
- Santasalo gear boxes
- Terry gear boxes
- Western gear boxes
- Winsmith gear boxes
- Custom Designs
- And many other
Click the picture below to enlargen the image.
Griffin Gear's engineers developed a superior gearing design platform to help their customers save time and cost. This is achieved by an exacting and modification method to your gearing and gearboxes. This process is not only a simple rebuild, it also is a long-life performance upgrade as well.
Griffin Gear provides portable coordinate measuring machines, hardness testers, and an extensive gearing software library. This equipment allows our engineering staff to provide the following services:
Rebuild your manufacturer's OEM gearing system with high quality replacement gears, shafts, housings, and other related gearing components.
Assist you with any and all gearbox modifications. These modifications can range from the most simplistic ratio changes to complex gearbox upgrades.
Griffin Gear can reverse engineer complete gearbox designs on the fly. This allows Griffin Gear to provide their customers with a complete drop-in replacement gearbox, and get you back up and running saving you on production loss, and down time costs.
Griffin Gear provides fast turnarounds, and adding value by their heat treating capabilities. Griffin Gear’s car-bottomed furnace has the ability to reach temperatures as hot as 1,400 degrees Fahrenheit. This also accommodates parts with large dimensions. The largest dimensions are 16 feet wide by 20 feet long, and 8 feet high.
Griffin Gear adds quality to your specifications according to national standards issued by AWS (American Welding Society). Griffin Gear monitors progress, and tracks progress by using up to 24 thermo-couplings.
Griffen Gear also uses a furnace, fired by a Maxon 3 inch KineMax Burned with 2,400,000 BTU/Hr! The control panel is equipped with a reliable Honeywell Burner, Temperature, and High Limit Control unit. A recording unit is provided by the Honeywell DPR180 with 24 inputs, and comes with a certificate of calibration.
Griffin Gear is also offers competitive pricing. Whether your part is 100 lbs. or a staggering 50,000 lbs. Griffen Gear will get the job done, and have the product shipped.
Griffin Gear has an automated, 50-ton capacity segment gear welding workstation. This workstation is also coupled with various welding power supplies, and fabrication tools. This allows Griffin Gear to fabricate a variety of industrial manufacturing equipment, and the equipment components.
Griffin Gear has a a variety of industrial welding equipment. This includes the Lincoln 350 and 400 amp industrial welders. Also in the line-up is an Airco 300 Amp MIG welder. This particular unit is the ideal industrial arc welder for it's power ratings. For heavy industrial applications Griffin uses 600 Amp industrial tig welders.
Griffin Gear's machine tooling includes surface grinders, vertical hones, band saws, drill presses, and stamping presses.
Click the picture below to enlargen the image.
Griffin Gear’s machining capabilities support very large components equipped with horizontal turning capabilities of up to up to 260 feet in length, and a 32 inch swing. Griffin Gear's large Scheiss VBM has the capability to turn 20 foot diameter units! For even larger volume or smaller turning requirements, Griffin's Mori Seiki CNC lathe has the ability to handle these production needs in an effecient, and exact manner.
Griffin Gear's Key Equipment consists of the following:
A Sharp CNC industrial lathe.
Many variations of engine lathes.
A Mori Seiki NL2400Y/1250 CNC industrial Lathe.
Scheiss industrial VBMs.
Super industrial Mill HBM units.
Griffin Gear also carries a variety of key Seaters,
Grinders, Thread Mills, and Horizontal Broaches.
Manufacturing Capabilities Page >>
Visit Griffin's Photo Gallery >>
The Largest Selection of Gearing Equipment and Expertise in the Southeast
Griffin Gear specializes in the manufacture of high quality replacement gearing, and gearbox rebuilds for any conceivable industrial application. Griffen Gear is your source for extremely large scale projects. The Griffin Gear manufacturing plant is stocked with ready made components, custom gearing, and gearbox building, rebuilding, and gearbox upgrades are also available upon request.
GGriffin Gear has the capability to machine and cut gears ranging in sizes from 1/2 inch diameters, to the massive gear sizes with diameters of 20 feet! Griffin Gear has the largest selection of industrial tooling equipment. Their tooling collection also includes metric machine tools. Covering both American standard and metric gearing needs. Griffin Gear's experience allows for highly customized gearing jobs.
To learn more about Griffin Gear's machine gear manufacturing capabilities contact RCS & Associates >> we are here to answer all your questions.
Griffin Gear offers a full range of proven industrial manufacturing services. Their advanced gearbox manufacturing facility currently spans over 100,000 square feet. The Griffin Gear facility will soon be expanding in the near future to meet the growing needs of their customers. Top notch customer service, and experienced engineers are there to assist you in your custom applications.
Griffin Gear was founded by Joe Griffin in 1967, as an expansion of the family's foundry business. Evolution of the Griffin Gear family business brought them to precision focus on the industrial gearing industry. This included; gearbox repairs, and gear-related industry applications. Today, Griffin Gear is partnered with Renaissance Power Systems. Renaissance Power Systems serves customers across the U.S. and Canada bringing you unprecedented access to turnkey industrial gearing, and machine gear solutions that minimize lead time and costs.
GRIFFIN GEAR'S MATERIAL EXPERTISE:
Many others are available
GRIFFIN GEAR IS AN AGMA MEMBER, AND CARRIES THE ISO 9001 COMPLIANT CERTIFICATION
Gearing Market Applications and Manufacturer Industries Served Overview
Griffin Gear specializes in the manufacturing of superior high quality replacements parts for every imaginable industrial application. Griffin Gear manufactures all types of long-life robust gears including worm gears, helical gears, bevel gears, spur gears, herring-bone gears, sprockets, double helical gears, rack and pinion gears, internal gears, spline gears, and many other gears types for custom applications are available based upon our customer’s needs. Because of our diverse customer base, Griffin Gear offers a wide array of gearing solutions for many industrial applications. Many of these industries are listed below. These industries are, but not limited to:
- Agriculture industry
- Aluminum industry
- Cement industry
- Chemical industry
- Dredging equipment
- Food processing
- Hospitals industry
- Machine shop
- Material handling
- Mining industry
- Ore processing
- Pulp & paper
- Railroads industry
- Rubber industry
- Steel industry
- Textiles industry
- Utility plants industry
- Water & waste
Griffin Gear has assisted their customers with specific and custom gearbox requirements. Many applications require special and precise gearbox specifications. Griffin Gear has the ability to create these made to order units. These units can be found in applications such as:
- Cooling towers
- Coal grinding &
- Exciter reduction
- Winch & breasting
- Turbine turning
- Mixers & agitators
- Drives conveyors
- Compressor drives
- Pump drives
- Turbine reductions
- Waste water
If you have a particular application you would like assistance with, please don't hesitate to call us at
We will gladly assist you in your gearing endeavour.
